99-7524B
9
Wiring Installation
Connections to be made to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
• Connect the Orange wire to the illumination wire. If the aftermarket
radio has no illumination wire, cap off the Orange wire.
•
Cap off and disregard the Orange/White wire, it will not be used in this
application.
• Connect the Blue wire to the antenna turn on wire.
•
Connect the Blue/White wire to the amp turn-on wire, if the vehicle is amplified
.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
•
Connect the Purple/Black wire to the right rear negative speaker output.
• 12-pin pre-wired ASWC-1 harness:
This harness is to be used along with the optional ASWC-1 (not included)
to retain steering wheel audio controls. If the ASWC-1 is not being used,
disregard this harness. If it will be used, please refer to the ASWC-1
instructions for radio connections and programming.
Note: Disregard the harness that comes with the ASWC-1.
