Metra Electronics 99-7581 - Dash Disassembly; Pathfinder 2005-2007;08-10 (S Models)

99-7581
1
NOTE:
Do not cycle the key while the dash is
removed or the air bag light will come on.
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
PATHFINDER 2005-2007/08-10 (s models)
Unclip and remove trim panel from
around cup holders in the center
console.
(Figure A)
2
Unclip and remove shifter trim panel
including pocket below radio and a/c
controls.
(Figure B)
3
Unclip and remove panel at top of
radio and remove (1) Phillips screw
underneath.
(Figure C)
4
DASH DISASSEMBLY
A
B
C
Unclip and remove entire trim panel
surrounding radio and including a/c
controls.
(Figure D)
5
D
Remove (4) Phillips screws securing
radio to remove.
(Figure E)
6
E
