Metra Electronics 99-7581 - Kit Assembly; ISO DIN Head Unit Provisions

99-7581
4
KIT ASSEMBLY
Mount the ISO brackets to the head
unit with the screws supplied with
the unit. (Figure A)
1
A
Slide the head unit into the radio
opening until the side clips engage.
(Figure B)
2
ISO DIN HEAD UNIT PROVISIONS
B
Snap the trim plate into the radio
housing.
(Figure B)
3
