Metra Electronics 99-7604 - Stacked ISO Units Provision

8
99-7604 KIT ASSEMBLY
B
C
A
STACKED ISO UNITS PROVISION
Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure B)
2
Slide the stacked ISO units into the
bracket/radio housing assembly and
secure the units to the kit using the
screws supplied with the units.
(Figure C)
3
Snap the Double DIN trim plate into the
radio housing. (Figure C)
4
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
1
Cut and remove the center bar from
the radio housing. (Figure A)
