Metra Electronics 99-7604 - ISO Mount Radio Provision with Pocket

6
99-7604 KIT ASSEMBLY
B
A
ISO MOUNT RADIO PROVISION WITH POCKET
Mount the ISO Brackets to the radio
with the screws supplied with the
radio. (Figure A)
1
Slide the radio into the radio housing
until it snaps into place. (Figure B)
2
Snap the ISO trim plate onto the front
of the Radio Housing. (Figure B)
3
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Snap the pocket into the radio housing.
(Figure C)
4
C
