99-7604 DASH DISASSEMBLY
INFINITI G35 2003-2004
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip the collar below the shift knob
and slide down. Using a small screw-
driver or hook tool remove the spring
clip to release and remove the shift
knob.
(Figure A)
2
3
Continue on page 2 .
Unclip the cup holder/shifter trim
panel. Unplug and remove panel.
(Figure B)
4
Remove (2) Phillips screws from the
bottom of the radio/climate control
panel.
(Figure C)
5
Remove (2) Phillips screws from the
panel below the steering column then
unclip and let the panel hang.
A
B
C
D
E
6
Remove (2) Phillips screws from the
accessory plug panel then unclip and
remove the panel.
(Figure D)
Unclip and remove the passenger side
kick panel then remove (1) Phillips
screw exposed behind the panel on
bottom right side of glove box.
(Figure E)
7
To Next Page
