Metra Electronics 99-7604 - Kit Assembly; DIN Radio Provision with Pocket

5
99-7604 KIT ASSEMBLY
B
C
A
DIN RADIO PROVISION WITH POCKET
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs outward. (Figure A)
1
Slide the aftermarket radio into the
cage until it snaps into place. (Figure B)
2
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Snap the pocket into the radio housing.
(Figure C)
3
