Metra Electronics 99-8713 - Page 4

2
99-8713
MERCEDES BENZ SLK CLASS 2005-2009
DASH DISASSEMBLY
7
Unclip and remove the climate control
unit. (Figure F)
8
Remove the (2) screws securing the
hazard switch panel and remove the
panel.
Figure G)
9
Open the beverage holder above the
radio and remove the (2) screw covers.
(Figure H)
10
Remove the (2) screws securing the
beverage holder then remove the unit.
(Figure I)
11
Remove the (4) screws securing the
radio then remove the unit.
(Figure J)
F
G
H
IJ
Continue to kit assembly.
