6
99-8713
KIT ASSEMBLY
2
A
Snap the Double DIN brackets to the
inside edge of the radio housing.
(
Figure B)
4
Snap the Double DIN trim-plate over
the front of the assembled Radio
Housing and stacked ISO units.
(
Figure C)
3
Slide the stacked ISO units into the
Double DIN bracket/radio housing
assembly and secure the units to the
kit using the screws supplied with
the units. (
Figure C)
Cut and remove the center bar from
the radio housing. (
Figure A)
1
B
C
STACKED ISO UNITS PROVISION
Note: Refer also to the instructions included with the aftermarket radio.
Continue to final assembly.
