Metra Electronics 99-8713 - ISO Radio Provision with Pocket

4
99-8713
KIT ASSEMBLY
2
A
Slide the radio into the radio housing
until the side clips snap into place.
(
Figure B)
3
Snap the Trim plate over the front of
the Radio Housing. (
Figure B)
4
Snap the Pocket into the Radio
Housing. ( Figure C)
Mount the ISO Brackets to the radio
with the screws supplied with the
radio. (
Figure A)
1
B
C
ISO RADIO PROVISION WITH POCKET
Note: Refer also to the instructions included with the aftermarket radio.
Continue to final assembly.
