99-8713
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove trim around shifter
knob including shifter boot.
(Figure A)
2
MERCEDES BENZ SLK CLASS 2005-2009
Unclip and remove entire panel sur-
rounding shifter starting at the rear
of the panel under the parking brake
handle.
(Figure B)
3
Unclip and remove the cigarette
lighter housing trim panel.
(Figure C)
4
Open the ashtray assembly and
remove the (2) screw covers on the
screws securing the assembly.
(Figure D)
5
Remove the (2) screws securing the
ashtray assembly then remove the
whole unit including the cigarette
lighter housing.
(Figure E)
6
DASH DISASSEMBLY
A
B
C
DE
