99-8907HG
Dash Disassembly
1. Unsnap and remove the outside
trim panel from the driver’s side
dash. (Figure A)
2. Remove (2) Phillips screws from
the driver knee trim panel and
remove the panel. (Figure B)
3. Remove (2) 10 mm nuts now
exposed and lower the driver
airbag assembly (no need to
disconnect). (Figure C)
(Figure A) (Figure B) (Figure C)
To Next Page
