DP-3021B
2
Dash Disassembly
1. Open the center console door,
remove the (2) nut covers and the
(2) 10mm nuts exposed. (Figure A)
2. Pull up on the rear of the traction/
ride control switch panel to release
it, and then unplug and remove.
(Figure B)
3. Remove the (2) 10mm nuts
exposed. (Figure B)
4. Open the ashtray door, and then
remove the (1) Phillips screws
exposed. (Figure C)
5. Remove the ashtray, and then
remove the (1) 9/32” screw
exposed. (Figure C)
Continued on the next page
(Figure B)(Figure A) (Figure C)
