DP-3021B
Dash Disassembly
3
(Figure D) (Figure F)(Figure E)
6. Unclip the small grille to the left
of the ignition switch, and then
remove the (1) 9/32” screw
exposed. (Figure D)
7. Unclip the radio dash panel starting
from the base of the center
console, unplug the cigarette
lighter, and then unclip and remove
the entire panel. (Figure E)
8. Remove the (2) 9/32” screws
securing the radio, and then
unplug and remove.
Convertibles only:
Remove the (2) T-15 Torx screws from
the top and the (2) T-15 Torx screws
from the lower sides securing the
center seat divider. Lift the seat divider
straight up to remove it. (Figure F)
Continue to Kit Preparation
