6
Year Make Model Pin Wire
Location Color
2003-05 Cadillac Escalade A1 Orange
2003-05 Chevy Avalanche A1 Orange
2003-05 Chevy Silverado A1 Orange
2003-05 Chevy SSR A1 Orange
2003-05 Chevy Suburban A1 Orange
2003-05 Chevy Tahoe A1 Orange
2002-05 Chevy Trailblazer A1 Orange
2002-05 GMC Envoy A1 Orange
2003-05 GMC Sierra A1 Orange
2003-05 GMC Yukon A1 Orange
2003-05 Hummer H2 A1 Orange
2005 Isuzu Ascender A1 Orange
2002-04 Oldsmobile Bravada A1 Orange
For the vehicles listed above use the
Pink wire on the SWC-01 and set the CAR DIP Switch settings as
follows:
Dip 1 Dip 2 Dip 3 Dip 4 Dip 5 Dip 6 Dip 7 Dip 8
Down Up Up Up Up Down Up Up
(GM Continued From Previous Page)
SWC-01
