Metra Electronics SWC-01 - Page 8

5
Year Make Model Pin Wire Additional Wiring Needed
Location Color
2000-05 Chevy Venture A7 Dk. Blue Connect A6, Pink, to a 12 volt accessory wire
2000-04 Oldsmobile Silhouette A7 Dk. Blue Connect A6, Pink, to a 12 volt accessory wire
2001-05 Pontiac Aztek A7 Dk. Blue Connect A6, Purple, to a 12 volt accessory wire
2000-05 Pontiac Montana A7 Dk. Blue Connect A6, Pink, to a 12 volt accessory wire
2003-04 GMC Sonoma A7 Dk. Blue Connect A6, Dk. Green, to chassis ground
For the vehicles listed above use the
Green wire on the SWC-01 and set the CAR DIP Switch settings as
follows:
Dip 1 Dip 2 Dip 3 Dip 4 Dip 5 Dip 6 Dip 7 Dip 8
Up Down Up Up Up Down Up Up
Year Make Model Pin Wire Additional Wiring Needed
Location Color
2004-05 Buick Century A7 Dk. Blue Connect A6, Purple, to chassis ground
2004 Buick Regal A7 Dk. Blue Connect A6, Purple, to chassis ground
2005 Chevy Equinox A9 Dk. Blue Connect A10, White/Black, to chassis ground
2004-05 Chevy Malibu A9 Dk. Blue Connect A10, White/Black, to chassis ground
For the vehicles listed above use the
Green wire on the SWC-01 and set the CAR DIP Switch settings as fol-
lows:
Dip 1 Dip 2 Dip 3 Dip 4 Dip 5
Dip 6 Dip 7 Dip 8
Down Down Down Up Up Down Up Up
Year Make
Model Pin Wire
Location Color
2004-05 Buick Rainier A1 Orange
For the vehicles listed above use the
Pink wire on the SWC-01 and set the CAR DIP Switch settings as follows:
Dip 1 Dip 2 Dip 3 Dip 4
Dip 5 Dip 6 Dip 7 Dip 8
Down Up Down Up Up Down Up Up
(GM Continued From Previous Page)
SWC-01
