METREL A 1532 XA User Manual

A 1532 XA EVSE adapter Safety and operational considerations
5
2 Safety and operational considerations
2.1 Warnings and notes
In order to maintain the highest level of operator safety while carrying out various tests and
measurements METREL recommends keeping your EVSE adapter in good condition and
undamaged. When using the adapter, consider the following general warnings:
 Warning on the A 1532 XA means »Read the Instruction manual with special
care for safe operation«. The symbol requires an action!
 If the A 1532 XA is used in a manner not specified in this Instruction manual or the
Instruction manual of target test equipment, the protection provided by the A 1532
XA and test equipment may be impaired!
 Read this Instruction manual carefully, otherwise use of the A 1532 XA may be
dangerous for the operator, for test equipment or for the tested object!
 Do not use the A 1532 XA if any damage is noticed!
 Mains test sockets and banana sockets are intended for test purposes only, as
described in this manual!
 Service intervention is allowed to be carried out only by a competent authorized
person!
 All normal safety precautions have to be taken in order to avoid risk of electric
shock when working on electrical installations!
 Consider maximal load current for intermittent and continuous operation!
2.2 Markings on the adapter
»Read the Instruction manual with special care to safety operation«. The
symbol requires an action!
Mark on your equipment certifies that it meets requirements of all subjected EU
regulations.
This equipment should be recycled as electronic waste.
This equipment is protected by reinforced insulation.

METREL A 1532 XA Specifications

General Data

input voltage	up to 250 V (1-phase), up to 430 V (3-phase)
frequency	50 Hz, 60 Hz
maximum test current	267 A (10 ms) intermittent operation
maximum load current	13 A, continuous operation
resistance BNC case to PE	100 kΩ
resistance BNC contact to CP	100 kΩ
altitude	up to 3000 meters above sea level

Operating Conditions

working temperature range	0 °C … 40 °C
maximum relative humidity (operation)	95 %RH (0 °C … 40 °C), non-condensing
storage temperature range	-10 °C … +70 °C
maximum relative humidity (storage)	90 %RH (-10 °C … +40 °C), 80 %RH (40 °C … 60 °C)

Weight and Dimensions

dimensions	10 cm × 7 cm × 25 cm
test lead(s) length	0.5 m
weight	0.90 kg
