A 1532 XA EVSE adapter Safety and operational considerations
6
2.3 Standards applied
The A 1532 XA adapter is manufactured and tested in accordance with the following
regulations:
Safety (LVD)
EN 61010 - 1
Safety requirements for electrical equipment for measurement, control
and laboratory use – Part 1: General requirements
EN 61010 - 2 - 030
Safety requirements for electrical equipment for measurement, control
and laboratory use – Part 2-030: Particular requirements for testing and
measuring circuits
EN 61010 - 031
Safety requirements for hand-held probe assemblies for electrical
measurement and test
Functional
EN 61851 - 1
Electric vehicle conductive charging system Part 1: General
requirements
Note about EN and IEC standards:
Text of this manual contains references to European standards. All standards of EN 6xxxx (e.g.
EN 61010) series are equivalent to IEC standards with the same number (e.g. IEC 61010) and
differ only in amended parts required by European harmonization procedure.

METREL A 1532 XA Specifications

General Data

input voltage	up to 250 V (1-phase), up to 430 V (3-phase)
frequency	50 Hz, 60 Hz
maximum test current	267 A (10 ms) intermittent operation
maximum load current	13 A, continuous operation
resistance BNC case to PE	100 kΩ
resistance BNC contact to CP	100 kΩ
altitude	up to 3000 meters above sea level

Operating Conditions

working temperature range	0 °C … 40 °C
maximum relative humidity (operation)	95 %RH (0 °C … 40 °C), non-condensing
storage temperature range	-10 °C … +70 °C
maximum relative humidity (storage)	90 %RH (-10 °C … +40 °C), 80 %RH (40 °C … 60 °C)

Weight and Dimensions

dimensions	10 cm × 7 cm × 25 cm
test lead(s) length	0.5 m
weight	0.90 kg
