MD 9250 Clamp Meter Series Specifications
19
1)
AutoCheck
TM
Ohm Threshold:
< 10.00M nominal
Audible Continuity Tester
Audible Threshold: Between 10 and 200
Response time: 32ms approx.
Capacitance
RANGE
Accuracy
1)
60.00nF, 600.0nF, 6.000F
2.0%+5d
60.00F,600.0uF
3.5%+5d
2)
2000F
4.0%+5d
2)
1)
Accuracies with film capacitor or better
2)
Temperature Coefficient: 0.25 x (specified accuracy)/ C @(0C -- 18C or 28C --
40C)
Diode Tester
RANGE
Accuracy
1.000V
1.0% + 3d
Test Current: 0.56mA typically
Open Circuit Voltage: < 1.8VDC typically
DCA Current (Clamp on)
RANGE
Accuracy
1) 2)
200.0A
2.0%+5d
0~500A
2.0%+5d
500~2000A
3.0%+5d
1)
Induced error from adjacent current-carrying conductor: <0.1A/A
2)
Specified with Relative Zero mode applied to offset the non-zero residual readings,
if any
ACA Current (Clamp on)
RANGE
Accuracy
1)
50Hz ~ 60Hz
200.0A
2.0%+5d
0~500A
2.5%+5d
500~2000A
3.0%+5d
40Hz ~ 50Hz & 60Hz ~ 400Hz
200.0A
2.0%+5d
0~500A
3%+5d
500~1000A
3.5%+5d
1000~2000A
indicative
True RMS Crest Factor :
< 1.4 : 1 at full scale & < 2.8: 1 at half scale
1)
Induced error from adjacent current-carrying conductor: < 0.1A/A
