MD 9250 Stromzange Serie Spezifikationen
36
Spannung AC+DC
Messbereich
Genauigkeit
DC, 50 Hz ~ 400 Hz
6 V, 60 V,
600 V und 1000 V
1,4 % + 7 d
Eingangsimpedanz: 10M, 50 pF (Nennwert)
AutoCheck_ACV
Messbereich
Genauigkeit
1)
50 Hz ~ 60 Hz
6 V, 60 V,
600 V und 1000 V
1,5 % + 5 d
AutoCheck
TM
Lo-Z AC V-Schwelle:
> 1,5 V (50/60 Hz) nominal
AutoCheck
TM
Lo-Z AC V-Eingangsimpedanz:
Initialwert ca. 2,5 k, 600 pF (Nennwert); Impedanzwert steigt innerhalb von
Sekundenbruchteilen stark an, da die Spannungsanzeige 50 V (normal) übersteigt.
Mögliche Impedanzwerte sind bei jeweiligen Spannungsgrößen:
10 k @ 100 V
60 k @ 300 V
200 k @ 600 V
420 k @ 1000 V
VFD_ACV (mit Tiefpassfilter)
Messbereich
Genauigkeit
1)
10 Hz ~ 20 Hz
6 V, 60 V,
600 V und 1000 V
4 % + 80 d
20 Hz ~ 200 Hz
6 V, 60 V,
600 V und 1000 V
2 % + 60 d
200 Hz - 400 Hz
2)
6 V, 60 V,
600 V und 1000 V
7 % + 80 d
1)
Nicht spezifiziert für Basisfrequenz > 400 Hz
2)
Genauigkeit linear abfallend von 2 % + 50 d bei 200 Hz bis 7 % + 80 d bei 400Hz
CREST-MAX Erfassungsmodus
Genauigkeit: Spezifizierte Genauigkeit plus 250 Ziffern bei Änderungen > 5 ms
Ohm und AutoCheck
TM
_Ohm
1)
Messbereich
Genauigkeit
600 , 6 k, 60 k
0,5 % + 5 d
600 K
0.8 % + 5 d
6M
1,2 % + 5 d
40 M
2,3 % + 5 d
Leerlaufspannung: 0,45 V DC (normal)
