C5 E-Series
Hot Food Holding Cabinets
L01-633
C5 E-SERIES SERVICE AND REPLACEMENT PARTS*
WARNING: Only factory approved service agents must attempt to service, repair or replace electrical components,
wiring or power cord.
Module CABINET BODY
Item# Replacement Part No. Description Item# Replacement Part No. Description
1 RPC13-1338 Power - selector switch 18 C5-USLIDEPR-C Universal wire slides (1 pair)
2
RPC13-721 Thermostat
19
RPC06-179 Plastic Drip Pan
3
RPC06-914 Thermostat Knob
20
RPC5E-DRIPTROUGH Drip Trough (includes screws)
4
RPC13-218 Thermometer
21
B5DN 5" swivel Caster
5
RPC13-096 Terminal Block
22
B5DNB 5" Brake Caster
6
RPHM20-2103 Fan 120V
23
RPC14-119 Door Hinge (qty 1)
RPHX20-2103 Fan 220-240V
24
RPC14-118 Door Handle
7
RPC13-365 1950Watt Heating Element 120V 25 RPC5E-DOOR Door (does not include hardware or gasket)
RPC13-370 1950Watt Heating Element 220-240V 26 RPC5-SHELF-S Accessory shelf
8
RPC13-367 675 Watt Heating Element 120V
27
RPC07-104 Door Gasket
RPC13-369 675 Watt Heating Element 220-240V
9 RPC11-191 Fan intake Collar
10 RPC11-185 Stainless Steel Water Pan
11 RPC5-SCLP Sensor and bulb Clamp Kit
12 RPC13-198 Thermal Cut-out
13 RPC5E-INTCVR Air Intake Cover
14
RPC5E-EXHCVR Air Exhaust cover
15
RPC13-359 Power cord (120V)
RPC13-247 Power cord (220-240V)
16 RPC07-055 Rubber grommet
17 RP-STRNRLF Strain Relief
*CHECK DATA PLATE ON REAR OF CABINET TO CONFIRM CABINET VOLTAGE BEFORE SELECTING PARTS
