Metrohm 930 Compact IC Flex ChS/PP/Deg Manual - Short Instructions

3.2 Rear
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
10
￭￭￭￭￭￭￭￭
930 Compact IC Flex ChS/PP/Deg (2.930.1360)
3.2 Rear
Figure 2 Rear
1
Bottle holder
2
Drainage tubing connection
For connecting the drainage tubing, which
guides escaped fluids away from the bottle
holder.
3
Knurled screws
For fastening the removable back panel.
4
Back panel
Removable. Enables access to the detector
chamber.
5
Drainage tubing connection
For connecting the drainage tubing, which
guides escaped liquids away from the detec-
tor chamber.
6
Transport locking screws
For securing the vacuum pump when trans-
porting the instrument.
