OID Screen Map (continued)
117 SYSTEM SETPOINTS
Shutdown On Low
Intake Trip Time
[ 20]seconds 0-999
116 SYSTEM SETPOINTS
Shutdown On Low
Intake Pressure/Lvl
[No ]
118 SYSTEM SETPOINTS
Low Intake Shutdown
Auto Reset
[Yes]
121 SYSTEM SETPOINTS
Deluge Valve
Engine Start
[Yes]
120 SYSTEM SETPOINTS
Pressure Switch
Engine Start
[No ]
119 SYSTEM SETPOINTS
Low Intake Shutdown
Auto Reset Time
[ 20]seconds 0-999
122 SYSTEM SETPOINTS
High System Pressure
Alarm
[175.0]psi 999.9
432 BATTERY 2
Constant C
xA^3 + xB^2 + xC + D
[ 0.00978]
433 BATTERY 2
Constant D
xA^3 + xB^2 + xC + D
[- 0.05642]
431 BATTERY 2
Constant B
xA^3 + xB^2 + xC + D
[ 0.0000]
430 BATTERY 2
Constant A
xA^3 + xB^2 + xC + D
[ 0.0000]
429 BATTERY 1
Minimum Amps
[ 0.1]
435 BATTERY 2
Minimum Amps
[ 0.1]
434 BATTERY 2
Volts per count
[1.0000000]
219 USER PREFERENCES
Charger failure
delay time
[ 5]seconds 0-999
220 USER PREFERENCES
Modbus Address
[ 1] 0-255
221 USER PREFERENCES
RS485 com port
Setting
[Device ]
222 USER PREFERENCES
Modbus/Printer baud
[9600]
223 USER PREFERENCES
Modbus Parity
[None]
319 TECH SCREENS
Pressure
Transducer
[Yes]
322 TECH SCREENS
Engine Overspeed
Alarm
[3600]rpm 1000-9999
321 TECH SCREENS
Engine Running
Speed
[600]rpm 200-999
320 TECH SCREENS
Weekly Test Start
Due Lamp Only
[NO]
323 TECH SCREENS
Pulses Per
Revolution
[0] 0-999
123 SYSTEM SETPOINTS
Engine Lockout
Latched
[NO]
124 SYSTEM SETPOINTS
Remote Start
Input Contact Type
[NO ]
324 TECH SCREENS
Mode Select
0=US, 1=EU
[1]
517 AUX SETPOINTS
Aux User Program # 1
Include in First-Up
[ ]
516 AUX SETPOINTS
Aux User Program # 1
Shutdown in Test
[ ]
224 USER PREFERENCES
RESTART
WIFI
[No]
