CONFIGURATION SCREENS: All parameters that control the operation of the controller can be viewed and
changed within the Configuration set point screens. Each set point is protected by a user password to prevent
unauthorized changes. The system set points are separated into five different group
s.
1 CONFIG
1) SYSTEM SETPOINTS
2) USER PREFERENCES
3) TECH SCREENS
1) SYSTEM SETPOINTS (Level 1 password): These setpoints adjust the conditions
for starting and stopping the engine.
2) USER PREFERENCES (Level 1 password): These setpoints adjust settings not
related to engine operation.
3) TECH SCREENS (Level 2 password): These setpoints are for factory/technician
purposes only and are used to fine tune special systems.
1) ANALOG SIGNALS (Level 2 password): These setpoints calibrate the analog
pressure and battery volt readings.
2) AUXILLIARY ALARMS (Level 2 password): These 12 user programs are used
to setup any auxiliary signals that need to be monitored.
2 CONFIG
1) ANALOG SIGNALS
2) AUXILLIARY ALARMS
Changing Values:
1) Navigate to the configuration set point screen that contains the value that needs to be changed.
2) Press [CHANGE/ENTER]. If a password has not been entered for a while, the “ENTER PASSWORD” screen will
be displayed. Use the [1] [2] and [3] buttons to enter the appropriate password.
3) Once the correct password level has been attained, the “CHANGE VALUE” screen for the value to be changed will
be displayed. An underscore cursor will appear beneath the first digit on the entry.
Use [UP] or [DOWN] arrow buttons to scroll the value of the digit with the cursor. Press [CHANGE/ENTER] to
accept each digit’s entry. The cursor will move to the right so the next digit can be changed. Pressing
[SILENCE/RESET/ESC] or the [SYSTEM STATUS] button will exit change mode without changing the original
value.
101 SYSTEM SETPOINTS
Engine Start
Pressure
[100.0]psi 0-999.9
101 CHANGE
V
ALUE
Engine Start
Pressure
[ 60] psi 0
-
9
99
ENTER PASSWORD:
****
Example of how to change a setpoint value:
Press the [1], [2], or [3] keys to
enter the password. The default
user password is 1111. This
can be changed by the user in
screen 214.
Press the [UP] and [DOWN]
arrow keys to change each
digit at the cursor, press
[CHANGE/ENTER] to accept
the digit and move the cursor
to the right. Press
[SILENCE/RESET/ESC] to
escape the change value screen
and to keep the original value.
