METRON FD4 User Manual

Page 32 of 34
File Name: Doc#586p.docx
It is recommended to set the log to the most current entry before scrolling. When scrolling, it is possible to move forward and
backward through roughly a full weeks worth of data. See figure 1.5 for register interpretation.
Figure 1.5
Figure 1.6 Figure 1.7
Description Modbus Registers Usage Notes For Read Only Registers
Event Historical Log Index 040107 Event Historical Log Index Value For Record Being Pointed To
Event Historical Log Event Number 040108 Event Historical Log Event That Occurred 1-21
Event Historical Log Event Month 040109 Event Historical Log Month Event Occured 1-12
Event Historical Log Event Day 040110 Event Historical Log Day Event Occured 1-31
Event Historical Log Event Year 040111 Event Historical Log Year Event Occurred 00-99
Event Historical Log Event Hours 040112 Event Historical log Hour Event Occurred 1-24
Event Historical Log Event Minutes 040113 Event Historical Log Minute Event Occurred 0-59
Event Historical Log Event Seconds 040114 Event Historical Log Second Event Occurred 0-59
**Toggle Bit 3 Of Modbus Register 040001 Or PLC Address V9001.3 To Increment Historical Event Log Record 0-499**
**Toggle Bit 4 Of Modbus Register 040001 Or PLC Address V9001.4 To Decrement Historical Event Log Record 0-499**
**Toggle Bit 7 Of Modbus Register 040001 Or PLC Address V9001.7 To View Most Current Historical Event Log Record**
Event/Alarm Description
Event Index #
Battery 1 Low Voltage Alarm Occurred 0
Battery 1 Low Voltage Alarm Cleared 1
First-Up Reset Occurred 2
First-Up Reset didn't Occur 3
Silence Pressed Occurred 4
Silence Pressed didn't Occurred 5
Battery 2 Low Voltage Alarm Occurred 6
Battery 2 Low Voltage Alarm Cleared 7
SPARE 1 Alarm Occurred 8
SPARE 1 Alarm Cleared 9
SPARE 2 Alarm Occurred 10
SPARE 2 Alarm Cleared 11
Charger 1 Fault Alarm Occurred 12
Charger 1 Fault Alarm Cleared 13
Charger 2 Fault Alarm Occurred 14
Charger 2 Fault Alarm Cleared 15
AC Power Failure Alarm Occurred 16
AC Power Failure Alarm Cleared 17
Engine Overspeed Alarm Occurred 18
Engine Overspeed Alarm Cleared 19
Engine Failed To Start Alarm Occurred 20
Engine Failed To Start Alarm Cleared 21
Engine Quit Alarm Occurred 22
Engine Quit Alarm Cleared 23
Low Oil Pressure Alarm Occurred 24
Low Oil Pressure Alarm Cleared 25
High Water Temperature Alarm Occurred 26
High Water Temperature Alarm Cleared 27
Pressure Transducer Alarm Occurred 28
Pressure Transducer Alarm Cleared 29
Low Fuel Level Alarm Occurred 30
Low Fuel Level Alarm Cleared 31
Low Coolant Temp Occurred 32
Low Coolant Temp Cleared 33
High Coolant Temp Occurred 34
High Coolant Temp Cleared 35
Battery 1 Fault Contact Occurred 36
Battery 1 Fault Contact Cleared 37
Battery 2 Fault Contact Occurred 38
Battery 2 Fault Contact Cleared 39
Stop Pushbutton Pressed Event 40
Stop Pushbutton Released Event 41
Event/Alarm Description
Event Index #
Engine Started/Running Event 42
Engine Stopped Event 43
Engine Overspeed Signal Occurred 44
Engine Overspeed Signal Cleared 45
Low Oil Pressure Signal Occurred 46
Low Oil Pressure Signal Cleared 47
High Water Temperature Signal Occurred 48
High Water Temperature Signal Cleared 49
Engine Lockout Signal Occurred 50
Engine Lockout Signal Cleared 51
Deluge Signal Occurred 52
Deluge Signal Cleared 53
Remote Start Signal Occurred 54
Remote Start Signal Cleared 55
Low Fuel Level Signal Occurred 56
Low Fuel Level Signal Cleared 57
Pressure Switch Signal Occurred 58
Pressure Switch Signal Cleared 59
Aux 2 Message Occurred 60
Aux 2 Message Cleared 61
Fuel Tank Leak Occurred 62
Fuel Tank Leak Cleared 63
Fuel Injector Fault Occurred 64
Fuel Injector Fault Cleared 65
ECM Switch Alt. Pos. Occurred 66
ECM Switch Alt. Pos. Cleared 67
EMC Warning Occurred 68
EMC Warning Cleared 69
EMC Failure Occurred 70
EMC Failure Cleared 71
Water Strainer Clog Occurred 72
Water Strainer Clog Cleared 73
Aux 9 Message Occurred 74
Aux 9 Message Cleared 75
Coil 1 failure Occurred 76
Coil 1 failure Cleared 77
Coil 2 failure Occurred 78
Coil 2 failure Cleared 79
System In Auto Event Occurred 80
System In Auto Event Cleared 81
System In Off Event Occurred 82
System In Off Event Cleared 83
System In Manual Event Occurred 84
System In Manual Event Cleared 85
