Metrotech 810 Line Tracer User Manual

7
2. 810 EQUIPMENT
The Metrotech 810 Line Tracer consists of standard and optional equipment.
All equipment is shown in Figure 2-1.
2.1 Standard Equipment
Part Number
Description Remarks
810 Transmitter .25 watt
810 or Receiver
800C025
(metric)
800B004 Conductive Direct Connect Cable
Attachment Ground Spike, and
Assembly Ground Plate
400C079 Carrying Case
600A001-E Operation Manual
Features of the Model 810 Transmitter and Receiver are discussed in detail in sections 2.4 and 2.5.
2.2 Optional Equipment
Part Number
Description Remarks
4820 (4”) Metroclamps* Optimally tuned to the 810
4890 (8”) Metroclamps* Compatible with other
4490 (4”) Metroclamps* Metrotech locators
4290 (2”) Metroclamps*
*jumper cable included with all clamps
183045 Headphones For use when locate site
is too noisy for audio tone
SON830 Sonde For tracing non-metallic
Pipe for conduit
600A071 VHS Video Tape SECAM Training Tape
600A072 VHS Video Tape PAL Training Tape
600A073 VHS Video Tape NTSC Training Tape
