Page 25 MODEL: VB750
KEY PART NO. QTY DESCRIPTION
1 VB-0001-09 1 VB-Bracket-RH
2 VB-0001-09 1 VB-Bracket-LH
3 VB-0004-09 1 VB Bottom Bracket-RH
4 VB-0004-09 1 VB-Bottom Bracket-LH
5 VB-00022 1 Hose Guard - Rear 1/2
6 VB-00023 1 Hose Guard - Front 1/2
7 VB-00016 1 Gearbox Torque Arm
8 VB-00026 1 Frame, Main
9 VB-00132 1 Belt Deflector
10 E00010-11-R 2 Left and Right Rear Side Panel 46" x 101"
11 E00019-550/700 1 Floor Complete, 78”x225"
12 VB-00129-2-08 1 Shield, Front Drive Shaft w/ Hinge
13 E00026 1 Hydraulic Hose Support
14 VB-00024 1 Front Splash Pan/Rock Guard
15 E20028 1 Front Gate Insert 1/4” x 39-3/4” x 81” Poly
16 E00005-09 1 Belt, Bottom Front Gate (79.5")
17 E00003 1 Bar, Bottom Front Gate
18 E21648 1 SMV Spade Mounting
19 E21649 1 SMV Socket Mounting
20 E21650 1 Manual Holder w/ Decal
21 PM10-11-05 1 SMV Sign
22 E21658 1 PTO Stand w/Rubber Strap
23 E21659-11 1 Inner Hitch Assembly
24
25 E21661 1 HHCS, 3/4-10 x 5, GR8
26 E21662-11 1 Collar
27 E21663 1 Nut, 3/4-10, Nylon Lock
28 1 Serial Number Plate
29 E00303-00 1 Shield, Front
30 VB-00025 4 Spacer
31 E20942 2 Hinge, Shield
32 E00016 1 Lock Assy
33 E00007 2 Bar, Axle Retainer
34 VB-00131 1 VB Back Gear Box Guard
35 VB-00130 1 VB Top - Front Gearbox Guard
36 1 Safety Chain, Towing, 40000 lb., Optional
37 VB-00208 4 Apron Slide Rails, 208”
38 E21664 2 Poly Floor Chain Spacer, 211”
39 E00010-11-F 2 Left and Right Front Side Panel 46" x 101"
40 3600-VB750-10 3 Floor Hold Down
MAIN FRAME & BOX PARTS
Models VB750
