Page 31 MODEL: VB750
AXLES, WHEELS, SPINDLES AND RELATED PARTS
Models VB750
KEY PART NO. QTY DESCRIPTION
1 E00170-VB 2 Arm Assembly
2 E00171-VB 4 Spindle 3-3/8” x 20-1/2”
VB-00148 4 Optional Spindle, 3 3/8” x 23 3/4”, For 600/55 x 26.5 Tire
3 E00172-VB 4 Seal, Hub,33772
4 E00173-VB 4 Bearing, Inside Wheel, 33275
5 E00176-VB 4 Hub, 873
6 E00177 4 Bearing, Outside Wheel, 460
7 E00178 4 Washer
8 E00179 4 Nut, Spindle
9 E00180 4 Cap, Hub Dust
10 E00181-VB 4 Wheel (Standard)
10A VB-00149 4 Wheel, 26.5 x 20”, 10 Bolt (Optional)
11 E00182 4 Pin, Cotter
12 E00183 40 Nut, Wheel Stud
13 E00184 40 Stud, Wheel
14 E00185 16 Hub Cap Bolts
15 E00186 4 Gaskets
16 E00174-VB 4 Cup, Inside, 33462
17 E00175 4 Cup, Outside, 453A
18 E00AX700 2 Bushing
19 E00WS15 4 Guide, Poly
E20528
