Page 41 MODEL: VB750
KEY PART NO. QTY. DESCRIPTION
1 VB-00073 1 Gear Box SRT12 (see separate parts listing) 10760
2 VB-00074 1 Right Panel 14152
3 VB-00075 1 Left Panel 14153
4 VB-00076 16 Bolt, Hex-Hd M14x45 3489
5 VB-00077 16 Nut M14-8G 1799
6 VB-00078 1 Cross Bar 14247
7 VB-00079 2 UCFC 208 Ø40 Bearing 9905
8 VB-00080 8 Bolt, Hex-Hd M14x40 3311
9 VB-00081 4 Bolt, Hex-Hd M18x45 9156
10 VB-00144 56 Knife, 15mm Thick 10796
11 VB-00145-09 112 Bolt, Hex-Hd M16x50x1.5 10833
12 VB-00086-09 112 Nut M16 10834
13 VB-00146 1 left Beater, 15mm Thick 14119
14 VB-00147 1 Right Beater, 15mm Thick 14118
15 VB-00089 1 Lubrication Kit 9878
16 VB-00150 1 Guard 14246
17 VB-00083 28 Optional Formed Forged Blade 14626
18 VB-00082 28 Optional Formed Forged Blade 14627
19 VB-750-13-R 1 RH Rock Wing
20 VB-750-13-L 1 LH Rock Wing
21 4 Bolt, 3/8-16x1-1/4 Gr5
22 4 Flat Washer, 3/8
23 4 Nut, 3/8-16
15 MM BEATER HEAD ASSEMBLY, STANDARD
Models VB750
