Page 45 MODEL: VB750
KEY PART NO. QTY DESCRIPTION
1 VB-00061 1 Complete Gearbox 15410-2.375
2 VB-00032 1 Housing 8979
3 VB-00033-11 1 Hub 2.375" Bore 15414
4 VB-00034 1 Circlip E 95 9066
5 VB-00035 1 Gear Z=54 8996
6 VB-00036 2 Bearing 6017 9067
7 VB-00037 2 Circlip I 130 9069
8 VB-00038 1 Pinion Z=12 9009
9 VB-00039 2 Key 12x8x30 4174
10 VB-00040 1 Gear Z=63 9007
11 VB-00041 2 Bearing 6208 10509
12 VB-00042 3 Circlip I 80 3435
13 VB-00043 1 Pinion Z=10 9008
14 VB-00044 1 Key8x7x25 3396
15 VB-00045 1 Gear Z=43 8670-2
16 VB-00046 1 Spacer 9010
17 VB-00047 2 Bearing 6305 8596
18 VB-00048 2 Circlip I 62 3433
19 VB-00049 1 Pinion Z=28 8670-1
20 VB-00050 1 Bearing 1538
21 VB-00051 1 Circlip E 50 3428
22 VB-00052 2 Oil Plug Ø1” Gas 9175
23 VB-00053 2 Oil Level Indic Ø1” Glass 1831
24 VB-00054 2 Plug 8625
25 VB-00055 2 Plug 8243
26 VB-00056 2 Oil Seal 85/130/12 9068
27 VB-00057 1 Gasket 9064
28 VB-00058 1 Cover 9065
29 VB-00059 8 Screw Hex-Hd M8 x 16 3284
30 VB-00060 1 Gasket 8671
APRON DRIVE GEARBOX
MODEL VB750
