Meyer Sound 750-LFC - DIMENSIONS WITH RIGGING

APPENDIX B: 750-LFC DIMENSIONS
34
NOTE: For dimensions and weight for the MG-LINA top grid and MCF-750 caster frame, refer to the MG-LINA/
750 Assembly Guide (PN 05.270.101.01) available at www.meyersound.com
.
750-LFC W/P dimensions with rigging
750-LFC W/P dimensions with rigging and rainhood installed
471mm
18.55in
547mm
21.55in
519mm
20.43in
750-LFC W/RIGGING
WEIGHT: 105 LBS
1 1/2 [38mm] U.S.
1 3/8 [35mm] E.U.
M20 thread at the bottom
530mm
20.88in
6mm
.25in
251mm
9.88in
277mm
10.90in
530mm
20.88in
6mm
.25in
71.1mm
2.80in
601.5mm
23.68in
251mm
9.88in
277mm
10.90in
