APPENDIX B: 750-LFC DIMENSIONS
750-LFC dimensions without rigging
750-LFC W/P dimensions without rigging and rainhood installed
554mm
21.8in
478mm
18.8in
515mm
20.3in
530mm
20.9in
6mm
.2in
279mm
11.0in
248mm
9.8in
1 1/2 [38mm] U.S.
1 3/8 [35mm] E.U.
M20 thread at the bottom
750-LFC NO RIGGING
WEIGHT: 89 LBS
530mm
20.9in
6mm
.2in
70.9mm
2.79in
601.2mm
23.67in
279mm
11.0in
248mm
9.8in
