3
Controls and Connectors .................................. 3
Dimensions ........................................................ 3
AC Power ........................................................... 4
Audio Input ........................................................ 5
Limiting and Protection Circuitry ..................... 6
Rigging ............................................................... 7
Complete Systems .............................................. 8
Verifying Polarity ............................................... 10
Coverage Angles and Polar Plots..................... 11
Array Design ...................................................... 14
Safety Summary................................................ 15
Specifications .................................................... 16
Contents
ATENCIÓN
:
ACCESO INTE
R
AUTORIZADO A PERSONAL
T
ACHTUNG
:
GEHÄUSE NIC
H
UND REPARATUR NUR DURC
ATTENTION
:
ENTRETIEN
E
INTERNES NE SONT AUTORI
U
PERSONNEL TECHNIQUE QU
A
UK WARNING
:
THIS APPA
NO OPERATOR SERVICEABLE
P
REFER SERVICING TO QUALIFI
E
WARNINGS:
THIS PRODUCT M
This surface may reach high t
To ensure proper operation, allo
w
clearance from this surface and
a
To reduce the risk of electric sh
o
No operator serviceable parts in
s
Refer servicing to qualified pers
o
To reduce the risk of fire or elec
t
do not expose this appliance to
r
!
Meyer Sound, B
e
1
2
3
1
3
2
Loop
Input
PUSH
Network
Service
Wink
Reset
Activity
Remote Monitor System
10A RMS
20A Peak
88-127V
~
50-60Hz
700W RMS MAX
Operational voltag
e
Turn on 80V
~
T
u
Turn on 160V
~
T
u
Auto-Voltage Sele
c
P
U
S
H
R
E
-
C
I
R
K
-
I
T
P
U
S
H
R
E
-
C
I
R
K
-
I
T
Controls and Connectors
European Rear User Panel
with IEC 309 connector
Dimensions
15.25"
13.55"
21.0"
20.5"
2.0"
9.55"
30.0"
21.0"
Front Side Top
All units in inches
20.50"
9.55"
14.26"
2.0"
Rear User Panel shown with the optional
Remote Monitoring System (RMS) panel
ATENCIÓN
:
ACCESO INTERNO SOLO
AUTORIZADO A PERSONAL TÉCNICO CALIFICADO
ACHTUNG
:
GEHÄUSE NICHT ÖFFNEN WARTUNG
UND REPARATUR NUR DURCH ELEKTROFACHKRÄFTE
ATTENTION
:
ENTRETIEN ET REPARATIONS
INTERNES NE SONT AUTORISEES QU'AU
PERSONNEL TECHNIQUE QUALIFIÉ
UK WARNING
:
THIS APPARATUS MUST BE EARTHED.
NO OPERATOR SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL
WARNINGS:
THIS PRODUCT MUST BE GROUNDED
This surface may reach high temperatures while in use.
To ensure proper operation, allow at least 6 inches
clearance from this surface and adequate ventilation.
To reduce the risk of electric shock do not remove cover.
No operator serviceable parts inside.
Refer servicing to qualified personnel.
To reduce the risk of fire or electric shock
do not expose this appliance to rain or moisture.
!
Meyer Sound, Berkeley, CA. USA
1
2
3
1
3
2
Loop
Input
PUSH
Active / Speaker Fault
2 +
3 +
10K
Balanced
Input Polarity
LO Limit
HI Limit
Network
Service
Wink
Reset
Activity
Remote Monitoring System
CQ
Earth / Chassis
1
Case
220K
ESD
P
U
S
H
R
E
-
C
I
R
K
-
I
T
P
U
S
H
R
E
-
C
I
R
K
-
I
T
Mains circuit
breakers
Signal input and
loop connectors
Power LED (green/red)
Input polarity switch
Low Limit (red)
High Limit (red)
Tie-wrap anchor
Mains AC inlet
Remote Monitoring
System panel
(if RMS is installed)
95-125V
~
50-60Hz
1400W RMS MAX
208-235V
~
50-60Hz
1400W RMS MAX
Auto-Voltage Select

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Meyer Sound CQ-2 and is the answer not in the manual?

Meyer Sound CQ-2 Specifications

CQ-1

Acoustical IconAcoustical
frequency response± 4 dB 40 Hz – 18 kHz
phase response± 90° 50 Hz – 16 kHz
maximum peak SPL136 dB
dynamic range> 110 dB
Coverage IconCoverage
-6 dB points horizontal80° (500 Hz – 16 kHz)
-6 dB points vertical40° (1.5 kHz – 12 kHz)
-10 dB points horizontal100° (500 Hz – 16 kHz)
-10 dB points vertical50° (1.5 kHz – 12 kHz)
Transducers IconTransducers
low frequency transducer15” diameter MS-15 cone
high frequency transducer4” diaphragm MS-2001CQ horn compression driver
Acoustical Crossover Point IconAcoustical Crossover Point
crossover point700 Hz
Amplifiers IconAmplifiers
typecomplementary power MOSFET output stages class AB/H
burst capability1240 Watts (620 Watts/channel)
THD, IM, TIM< .02 %
Audio Input IconAudio Input
input impedance10 kΩ electronically balanced
connector typeXLR (A-3) male and female
nominal input level+4 dBu (1.23 Vrms)
AC Power IconAC Power
connector250 V NEMA L6-20P / IEC 309 Twistlock male receptacle
voltage selection85 – 134 V / 165 – 264 V; 50 Hz / 60 Hz
max continuous RMS current 115 V8 A
max continuous RMS current 230 V4 A
max burst RMS current 115 V15 A
max burst RMS current 230 V8 A
max peak current during burst 115 V22 Apk
max peak current during burst 230 V11 Apk
inrush current< 12A @115V
Physical IconPhysical
dimensions21” W x 30” H x 22 1/2” D
weight130 lb (59 kg)
shipping weight150 lb (68 kg)
enclosure/finishAll birch plywood/black textured
protective grillPerforated steel grill, charcoal-grey foam
rigging fittingsFour aircraft pan fittings (two on top and bottom)
working load per fitting500 lb

CQ-2

Acoustical IconAcoustical
frequency response± 4 dB 40 Hz – 18 kHz
phase response± 90° 50 Hz – 16 kHz
maximum peak SPL139 dB
dynamic range> 110 dB
Coverage IconCoverage
-6 dB points horizontal50° (800 Hz – 12 kHz)
-6 dB points vertical40° (1.5 kHz – 12 kHz)
-10 dB points horizontal60° (800 Hz – 12 kHz)
-10 dB points vertical50° (1.5 kHz – 12 kHz)
Transducers IconTransducers
low frequency transducer15” diameter MS-15 cone
high frequency transducer4” diaphragm MS-2001CQ horn compression driver
Acoustical Crossover Point IconAcoustical Crossover Point
crossover point900 Hz
Amplifiers IconAmplifiers
typecomplementary power MOSFET output stages class AB/H
burst capability1240 Watts (620 Watts/channel)
THD, IM, TIM< .02 %
Audio Input IconAudio Input
input impedance10 kΩ electronically balanced
connector typeXLR (A-3) male and female
nominal input level+4 dBu (1.23 Vrms)
AC Power IconAC Power
connector250 V NEMA L6-20P / IEC 309 Twistlock male receptacle
voltage selection85 – 134 V / 165 – 264 V; 50 Hz / 60 Hz
max continuous RMS current 115 V8 A
max continuous RMS current 230 V4 A
max burst RMS current 115 V15 A
max burst RMS current 230 V8 A
max peak current during burst 115 V22 Apk
max peak current during burst 230 V11 Apk
inrush current< 12A @115V
Physical IconPhysical
dimensions21” W x 30” H x 22 1/2” D
weight130 lb (59 kg)
shipping weight150 lb (68 kg)
enclosure/finishAll birch plywood/black textured
protective grillPerforated steel grill, charcoal-grey foam
rigging fittingsFour aircraft pan fittings (two on top and bottom)
working load per fitting500 lb
