MINA OPERATING INSTRUCTIONS
37
TIP: The MG-MINA grid can travel installed on
top of MINA stacks.
TIP: Durable nylon covers, sized for stacks of 3,
4, and 5 units, are available to ensure the MINA
is completely road ready.
Safety Guidelines for the MCF-MINA Caster
Frame
■ Do not stack more than five MINAs.
■ Avoid moving stacks in the front-to-back direction of the
MINAs (the long side); always move stacks sideways to
avoid tipping.
■ When transporting a non-curved MINA stack with
0-degree splay angles, configure the rear GuideALinks
for the bottom MINA so it is attached to the caster frame
at 0 degrees (using the 5-degree hole in the MINA
GuideALinks).
■ When transporting a curved MINA stack with wide splay
angles, configure the rear GuideALinks for the bottom
MINA so it is attached to the caster frame at –5 degrees
(using the 0-degree hole in the MINA GuideALinks), to
compensate for the stack’s center of gravity.
■ When groundstacking MINAs with the caster frame,
make sure that all four caster wheels are blocked to pre-
vent the stack from rolling away.
MCF-MINA Caster Frame with MINA Stack
0
3
6
9
11
0
3
6
9
11
0
3
6
9
11
0
3
6
9
11
0
3
6
