APPENDIX A: COMPARISON OF RMS MODULES
56
MPS-488HP
(HMS-5, HMS-10, HMS-
12, MM-4XP, MM-4XPD,
MM-XPV, MM-10XP,
UP-4XP, UPM-1XP, UPJ-
1XP, UPJunior-XP, UMS-
1XP)
Wink/Activity LED (Green):
■ Blinks 10 ten times when powering up
the loudspeaker.
■ Unlit, after powering up, if the loud-
speaker is not discovered.
■ Flashes continuously when the loud-
speaker is discovered, and flashes
more rapidly with increased data activ-
ity.
Identify Button:
■ Press to identify the MPS-488HP on
the RMS network during the discovery
process.
■ Press to wink the discovered
MPS-488HP.
■ Press and hold when powering up the
MPS-488HP to undiscover it.
2 Weidmuller
connectors
None
(Always
Enabled)
Table 3: RMS Module
RMS Module LEDs Buttons RMS Network
Connectors
Mute
Enable
