APPENDIX A: COMPARISON OF RMS MODULES
Table 3 documents the differences between the RMS modules. Loudspeakers with asterisks (*) come standard with the
RMS module.
Table 3: RMS Module
RMS Module LEDs Buttons RMS Network
Connectors
Mute
Enable
HP/MP
(PN 40.033.071.01)
(Acheron 100,
Acheron 80, Acheron LF,
600-HP, 700-HP, 650-P,
DF-4, DS-2P, DS-4P,
M2D-Sub
*, M3D*,
M3D-Sub
*, MICA*,
MILO 60
*, MILO 120*,
MSL-4, MSL-6, MTS-4,
PSM-2, PSW-2, PSW-4,
PSW-6, SB-1, SB-2,
SB-3F)
Service LED (Red):
■ Blinks once every 2 seconds if the
loudspeaker is connected to network
and not yet discovered.
■ Lights solid when the loudspeaker
encounters an RMS hardware failure.
Wink LED (Green):
■ Lights solid when the loudspeaker is
winked from the RMS program.
Activity LED (Green):
■ Flashes continuously when the loud-
speaker is discovered.
Service Button:
■ Press to identify the loudspeaker on
the RMS network during the discovery
process.
■ Press and hold with the Reset button
to reset and undiscover the loud-
speaker.
Reset Button:
■ Press to reboot the RMS firmware
without discovering the loudspeaker.
■ Press and hold with the Service button
to reset and undiscover the loud-
speaker.
2 Weidmuller
connectors
Jumper
(pins J3)
UltraSeries UX
(PN 40.084.008.01)
(500-HP, JM-1P, M1D,
M1D-Sub
*, M’elodie*,
MJF-212, MJF-212A,
UMS-1P, UPJ-1P,
UPJunior, UPM-1P,
UPM-2P, UPQ-1P,
UPQ-2P)
UltraSeries UPM
(PN 40.076.028.01)
(Acheron Studio, M2D*,
UPA-1P, UPA-2P, UM-1P,
UM-100P, USM-1P,
USM-100P, USW-1P)
Service LED (Red):
■ Blinks once every 2 seconds if the
loudspeaker is connected to network
and not yet discovered.
■ Lights solid when the loudspeaker
encounters an RMS hardware failure.
Wink LED (Green):
■ Lights solid when the loudspeaker is
winked from the RMS program.
Activity LED (Green):
■ Flashes continuously when the loud-
speaker is discovered.
Service Button:
■ Press to identify the loudspeaker on
the RMS network during the discovery
process.
■ Press and hold with the Reset button
to reset and undiscover the loud-
speaker.
Reset Button:
■ Press to reboot the RMS firmware
without discovering the loudspeaker.
■ Press and hold with the Service button
to reset and undiscover the loud-
speaker.
2 Weidmuller
connectors
Jumper
(pins J3)
DX
(Acheron Designer,
MINA*, X-400C,
MJF210
*)
Wink/Activity LED (Green):
■ Blinks 10 ten times when powering up
the loudspeaker.
■ Unlit, after powering up, if the loud-
speaker is not discovered.
■ Flashes continuously when the loud-
speaker is discovered, and flashes
more rapidly with increased data activ-
ity.
Identify Button:
■ Press to identify the loudspeaker when
discovering.
■ Press to wink the discovered loud-
speaker.
■ Press and hold when powering up the
loudspeaker to undiscover it.
2 Weidmuller
connectors
Recessed
switch on
RMS user
panel
MX
(LEO-M*, 1100-LFC*,
LYO N) *
Wink/Activity LED (Green):
■ Blinks 10 ten times when powering up
the loudspeaker.
■ Unlit, after powering up, if the loud-
speaker is not discovered.
■ Flashes continuously when the loud-
speaker is discovered, and flashes
more rapidly with increased data activ-
ity.
Identify Button:
■ Press to identify the loudspeaker when
discovering.
■ Press to wink the discovered loud-
speaker.
■ Press and hold when powering up the
loudspeaker to undiscover it.
2 Weidmuller
connectors
Jumper
(pins J3)
