MFJ-784B Instruction Manual
Introduction Error! Main Document Only.-6
Back Panel Layout
Power: 10-16 Vdc @ .5 amp peak (low "Z " audio load)
Headphones Out: 1/4" stereo or mono phone jack
Speaker Out: 3.5 mm stereo or mono phone jack
Filtered Audio Adjust: screwdriver adjustable potentiometer
Filtered Audio Out: RCA phono jack (~1.5 V P-P @ 600 ohms)
Receive Audio Adjust: screwdriver adjustable potentiometer
Receive Audio In: RCA phono jack
To Radio: 5-pin DIN jack
(TNC xmit audio, ground, PTT, receive audio in, T/R)
To TNC: 5-pin DIN jack
(TNC xmit audio, ground, PTT, filtered audio out)
For an in-depth description of the back panel connections, refer to Chapter
2, Installation.
