MFJ-784B Instruction Manual
Advanced Features Error! Main Document Only.-12
Data Mode Jumper Settings Chart
JMP
1
JMP
2
JMP
3
JMP
4
Mark-Space
(Shift)
L L L L 1215-1385 Hz (170)
L L L H 1275-1445 Hz (170)
L L H L 1415-1585 Hz (170)
L L H H 1615-1785 Hz (170)
L H L L *
2125-2295 Hz (170)
L H L H 1200-1400 Hz (200)
L H H L 1260-1460 Hz (200)
L H H H 1430-1630 Hz (200)
H L L L 1600-1800 Hz (200)
H L L H 2025-2225 Hz (200)
H L H L 2110-2310 Hz (200)
H L H H 2125-2325 Hz (200)
H H L L 1275-1700 Hz (425)
H H L H 2125-2550 Hz (425)
H H H L 1275-2125 Hz (850)
H H H H 2125-2975 Hz (850)
JMP
5
JMP
6
JMP
7
Baud Rate
L L L *45
L L H 57
L H L 75
L H H *100
H L L 110
H L H 150
H H L *200
H H H *300
* Factory defaults.
Data filter center frequency = (mark + space)
÷
2
Data filter bandwidth = (1.2 x shift) + (baud rate) (ref.: ARRL Handbook)
