MFJ-1278B MULTI-MODE HARDWARE
TTL INTERFACE PORT PIN FUNCTION,J5
The MFJ-1278B provides the user with a TTL level I/O port, J5. The TTL level I/O port, J5
is compatible with computers and terminals that do not support RS-232C serial voltage
levels, such as the Commodore C64 and C128 computers. Voltage levels of 0 and 5 VDC are
available at J5. Below in Table 8-3 is the pin out of the TTL level I/O port, J5:
Table 8-3 TTL Port, J5 Pin Out
J5 Pin # Pin Function
1 Receive Data
2 Data Carrier Detect
3 Ground
4 Request to Send
5 Transmit Data
6 Data Set Ready
7 Clear to Send
8 Frequency Shift Keying
9 Space Output for Scope
10 Mark Output for Scope
