Bulb Replacement
165
5
Replacement bulbs:
1. Brake light 21 watts
2. Tail light 10 watts
3. Fog guard light 21 watts
4. Reversing light 21 watts
5. Direction indicator light 21 watts
Detach the electrical connector from the light unit by depressing
the release catch (arrowed in inset) and then pulling the connector
from the light unit.
Raise the lever set into the rear face of the light unit. This will
release the light unit, which can then be withdrawn from the car.
Push and twist the bulbs anti-clockwise to remove.
When refitting, ensure the lever on the light unit is securely
clipped into the light unit housing and that the electrical connector
is correctly attached.
3
1
2
5
4
