MGI DNBSEQ-T7 - Rear View

Basic components
17
No. Name Description
1
Flow cell
orientation
marker
Shows the direction of placing the flow cell.
Rear view
1
2
3
4
5
7
6
Figure 7 Rear view
No. Name Description
1 Handle
Holds it to easily disassemble the rear panel
during maintenance.
