Blaze EMS-2 Operating Manual Page 37
4.11.2 UL Power ECU
Connect the UL Power Engine to the EMS-2 RS232 port using the UL Power cable
E080305 (RS232-EFIS cable).
ECU/AIR TEMP (UL Power ECU only):
Select whether you want the temperature to be displayed in degrees Celcius (ºC) or in degrees Fahrenheit (ºF).
UL Power display screen
A dedicated display screen will be shown when the UL Power is selected for the ECU type.
Alternating Display Area
Oil pressure, Oil Temperature, Fuel Pressure, OAT, Throttle position, ECU temperature, air temperature, Volts and
optional current is displayed here.
Warning Messages from the UL Power ECU
RPM
Fuel Flow
Ignition 1 Indicator
Green = On
Red = Off
Alternating display area
CHT display
EGT Display
Ignition 2 Indicator
Green = On
Red = Off
