8
68D5301
• Finishing
Combustible Finishing Material - Materials made of or surfaced with wood, com-
pressed paper, plant fibers, plastics or any material capable of igniting and burning,
whether flame proofed or not, plastered or unplastered (this includes drywall).
Noncombustible Finishing Material - Materials which will not ignite and burn. Such
materials are those consisting entirely of steel, iron, brick, tile, concrete, slate, glass
or plasters or combinations thereof or have a fire rating of zero.
• Finishing Checklist
Power supply service must be completed prior to finishing to avoid reconstruction.
Grilles and air openings cannot be covered under any circumstances.
NOTE: The heater is a zero clearance fireplace and may be finished with combus-
tible or noncombustible finishing materials.
When using paint or lacquer to finish the mantel, they must be heat resistant to pre-
vent discoloration.
WARNING: Con-
trol panel door on
this heater cannot,
in any way, be covered as it
may create a re hazard.
• WEF33 and WEF36 - 120V AC Installation
Once the site has been prepared, your fireplace can be installed.
1. Make sure power switch is in the OFF position.
. Plug fireplace into a 15-amp/10 Volt, grounded outlet. For WEF36, you will need
to purchase WEFCORD and connect to the wiring as a 10 volt AC, before plug-
ging into a 15 amp/10 volt, grounded outlet.
3. Push fireplace insert so trim is against finished mantel or wall surface.
• WEF36 - 240V AC Installation
1. Loosen the screw securing the junction box cover and remove cover.
. Complete the wiring following the wiring diagram on the box or in the homeown-
er's manual.
3. Make sure this wiring has a dedicated 0 amp fuse.
4. Place all connectors inside the fireplace and replace junction box cover.
