M‑I SWACO MONGOOSE PRO Shale Shaker
50 Field Installation and Operation Manual 9092F02001AENG (D) 50
ITEM
NUMBER
PART
NUMBER
DESCRIPTION
QTY
NOT SHOWN
103057238
BOLT M20 X 90MM FOR SHIPPING BLOCK
2
NOT SHOWN
04-1839
BOLT M20 X 160MM FOR SHIPPING TUBE
2
NOT SHOWN
04-1131
BOLT M8 X 30MM
9
NOT SHOWN
03-232
NUT M8
4
NOT SHOWN
05-276
FLATWASHER M8
18
NOT SHOWN
05-432
SCHNORR WASHER M8
9
NOT SHOWN
04-1105
BOLT M12 X 35MM
40
NOT SHOWN
04-1270
BOLT M12 X 45MM
10
NOT SHOWN
03-415
NUT M12
40
NOT SHOWN
05-305
FLATWASHER M12
80
NOT SHOWN
05-371
SCHNORR LOCKWASHER M12
40
NOT SHOWN
BM6Y10137-01
WASHER 0.48” ID X 1.25” OD X 0.135” THICK
4
*Motor kits MUST be ordered when replacing a motor. For a parts breakdown of each Motor Kit, refer to Table 9.
