M‑I SWACO MONGOOSE PRO Shale Shaker
53 Field Installation and Operation Manual 9092F02001AENG (D) 53
20.1.1.4 Quad MONGOOSE PRO Rig Critical Spares
Figure 39. Quad MONGOOSE PRO Shale Shaker Components Exploded View
Table 8. Rig Critical Spare Parts List For Quad MONGOOSE PRO Shale Shakers
ITEM
NUMBER
PART NUMBER
DESCRIPTION
QTY
NOT SHOWN
IN FIGURE
SEE TABLE 5
RIG CRITICAL SPARE PARTS LIST FOR MONGOOSE PRO
2
2
103057238
HHCS M20-2.5 X 90 MM LG, GRADE 10.9, XYLAN PLATED
16
3
05-244
LOCK WASHER SCHNORR M20 MARTIN
16
4
103058511
HEX NUT M20 MS GR 8.8 XYLAN 1424 D6586 BLACK COATING,
OVERTAP
16
5
3916067
GASKET, FULL FACE ANSI FLANGE 150 LBS., 10”
3
6
05-308
FLAT WASHER M24 REGULAR
96
7
1493001
HHCS M24-3 X 110MM LG, GRADE 8.8, XYLAN PLATED
12
8
05-373
LOCKWASHER SCHNORR M24
48
9
03-412
HEX NUT M24
48
10
1493002
HHCS M24-3.0 X 180 MM, GRADE 8.8, XYLAN PLATED
24
11
103057244
HHCS M24-3.0 X 90 MM, XYLAN PLATED
12
