3. Working environment
Receiver
Working temperature : -20℃~+70℃
Storage temperature : -20℃~+80℃
Working voltage: +12V
TPMS sensor：
Working temperature：-20℃~+85℃
Storage temperature： -20℃~+105℃
4. System installation
（1）Receiver installation
Correct installation Incorrect installation Incorrect installation
Receiver installation instructions:
Receiver must be 20cm away from large sources of interference such as in-car DVD, navigation, mobile
TV.Data cable and receiver cannot be wound or put on DVD.
(2) External sensor installation
a. Remove tire valve cap b. Screw in hexagon nut
