What’s needed for the integration?
1. OEM Dual Camera Mount (Qty 1)
2. 6-pin 60cm cable (Qty 2)
3. Dual Camera System Cable (Qty 2)
4. 2-prong mount (Qty 1)
5. Circuit Board w/ heat shrink (Qty 1)
6. VHB tape (Qty 3)
7. M3 X 10mm black-oxide Screws
(Qty 6)
8. M2 X 8mm Screws (Qty 2)
9. M3 Lock Washers (Qty 6)
10. Hex Key 2.5mm (Qty 1)
11. Loctite threadlocker (Qty 1)
12. Zip Ties (Qty 6)
13. 2-pin DF-13 power cable (Qty 1)
14. Alcohol Wipe (Qty 1)
Images shown are not to scale
Notes: Kit content may differ as hardware may already be installed.
Dual camera configuration requires the use of a DLS 2; a RedEdge-M can be used, but
an upgrade to the DLS 2 is required for software compatibility and support.
Rev 01 - March 2020
PAGE 3
