2 Player and Remote Overview
2.1 Connections and Ports
Name
Description
1
IR Input jack for optional external infrared remote control sensor.
Compatible with 38kHz external IR sensors.
2
IR Window Infrared remote control sensor window.
3
USB 1 USB 2.0 host jack for connecting USB storage drives.
4
SD Memory card reader for micro SD/SDHC memory cards.
5
AV Composite video and analog Left/Right audio output to a TV
or home theater with analog A/V input.
6
USB 2 USB 2.0 host jacks for connecting USB storage drives.
7
RECOVERY Pin-hole button for recovery mode.
8
HDMI Provides digital audio/video to a TV or home theater with
HDMI input.
9
DC 5V DC power input, 5V/2A nominal. Only use the AC adapter
provided with the player.
NOTE: The IR input jack is used in conjunction with an optional external infrared remote control
sensor (not included). This allows the player to be hidden behind other equipment, with the
external remote control sensor installed in clear view to receive signals from the remote control.
Usage of the external remote control sensor is optional as the player has a built-in remote
control sensor.
