11OPERATING MANUAL
1. Pre ow time (0.3 – 20 Seconds)
2. Starting Amperage (10 – 200A)
3. Up-slope time – (0 – 10 Seconds)
4. Peak Amperage TIG (10 – 200A) STICK (10-170A)
5. Base Amperage (10 – 200A Pulse only)
6. Down-slope time – (0 – 10 Seconds)
7. Ending Amperage (10 – 200A)
8. Post ow time (0.3 - 20 Seconds)
9. Pulse Frequency (0.1 – 200 Hz)
10. Pulse Ratio (5 -95 %)
11. AC Frequency (50 – 160 Hz)
12. AC Balance (10 – 50 %)
Unpacking
1. Remove cartons, bags or Styrofoam containing the welder and accessories.
2. Check the contents with the packing list below.
Item QTY
ACDC inverter power source 1 unit
Argon regulator 1pc
5m 26 series premium TIG torch 1pc
3m twist-lock electrode holder 1pc
3m earth clamp 1pc
4m gas hose 1pc
TIG torch accessories pack inc:
Tungsten, long & short cap, 6,8 & 10 alumina, collet
and collet body suit 1.6 & 2.4mm tungstens
1pc
Operator’s Manual 1pc
3. After unpacking unit, inspect carefully for any damage that may have occurred
during transit. Check for loose, missing, or damaged parts. Shipping damage
claim must be led with carrier.
