MICROMATIC.COM | 866-327-4159 POWER PACK SERVICE MANUAL | 3
EQUIPMENT SPECIFICATIONS
MODEL MMPP4301-EP MMPP4301 MMPP4301-WC MMPP4301-PKG MMPP4301-PKG-WC
Type Air Cooled Air Cooled Water Cooled* Air Cooled Water Cooled*
BTUs* 2,300 2,300 2,300 2,300 2,300
Compressor HP 1/3 1/3 1/3 1/3 1/3
Glycol Pumps 1 1 1 2 2
Pump Type
Vertical Rotary Vane Rotary Vane Rotary Vane Rotary Vane
Pump GPH
240 80 80 80 80
Pump Motor HP
1/3 1/3 1/3 1/3 1/3
Pump Inlet/Outlet Barbs 9.52mm (3/8”) 9.52mm (3/8") 9.52mm (3/8") 9.52mm (3/8") 9.52mm (3/8")
Plug Type
5-15P 5-15P 5-15P L5-30P L5-30P
Voltage
115 115 115 115 115
Amps (Running) 7.0A 12.1A 11.6A 17.7A 17.2A
Refrigerant R134a R134a R134a R134a R134a
Charge (oz.)
0.28 kg (10 oz) 0.34 kg (12 oz) 0.34 kg (12 oz) 0.34 kg (12 oz) 0.28 kg (10 oz)
Refrigerant
Running Pressures
18 (low) / 140 (high)
18 (low)
140 (high)
18 (low)
140 (high)
18 (low)
140 (high)
18 (low)
140 (high)
Dimensions
L x W x H Including
pump(s) and motor(s)
26.12" x 17.12"x 21.56” 30" x 18" x 27.75" 30" x 18" x 28.75" 30" x 18" x 27.75" 30" x 18" x 28.75"
Weight (lbs) 41 kg / 90 lbs 55 kg / 120 lbs 55 kg / 120 lbs 58 kg / 128 lbs 58 kg / 128 lbs
Bath Capacity (gal) 4.5 gal / 17 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L 11.5 gal / 43.5 L
Bath Insulation
Thickness
1.5" 1.5" 1.5" 1.5" 1.5"
Inlet Water Pressure NA NA
Min 40 psi
Max 120 psi
NA
Min 40 psi
Max 120 psi
Water Inlet & Outlet Fitting NA NA 9.52mm (3/8") NA 9.52mm (3/8")
Minimum Water Pipe Size NA NA 3/8" NA 3/8"
Approval
ETL Listed ETL Listed ETL Listed ETL Listed ETL Listed
*Rated at 20° F evaporator temperature and 90° F ambient temperature. †.3GPM, water is only used when the temperature of the condenser rises high enough
to open the cooling inlet valve. This is approximately 40% of the operating time depending on the ambient temperature and usage. Condenser Inlet Water
Temperature: Minimum 45° F / Maximum 80° F
